PARAMETERS
| MODEL | YQ-JQR-01 |
| Installation method | Ground installation |
| With a heavy wrist | 450kg |
| Maximum arm span radius | 3.2m |
| number of axles | 4 |
| positional repeatability | 0.2mm |
| protection grade | ip67 |
| range of motion | Rotation+180 to -180 85/s vertical arm+85 to -42 85/s horizontal arm+120 to -20 85/s wrist rotation+300 to -160 160/s |
| Robot weight | 2300kg |
| ambient temperature | 0-50° c |
| maximum humidity | 95% |
CHARACTERISTICS
·The advanced control system can communicate with other systems of the whole line through bus or other means.
·Small footprint is suitable for customers with compact design, making full use of smaller space.
·Flexible grabbing can realize grabbing, packing and stacking of products at any position.
·Compatibility can quickly replace the fixture to adapt to a variety of products.
