CHARACTERISTICS
·High degree of automation: using PLC+display screen control, the process is fully automated. Early warning of material shortage and automatic shutdown when there is no material available, easy to operate.
·Wide applicability: Suitable for various sizes and specifications of cardboard boxes.
·Stability and durability: The main components of the equipment are the deceleration motor PLC、 The touch screen, photoelectric switch, etc. are all made of internationally renowned brands.
·High safety performance: Comprehensive safety protection devices ensure safety during the production process.
PARAMETERS
| MODEL | YQKX-40 |
| Unboxing speed | Stable 40/minute, up to 50 boxes/minute |
| Machine size | L3800×W1480×H2250mm |
| Machine weight | 1500kg |
| Applicable carton size | L200-500mm*W200-500mm*H120-500mm |
| Mesa Height | Min1080mm (can be customized according to requirements) |
| power supply | 380V、50/60HZ、1.5kw |
| Gas source | 5Kg/ cm²、150L/min |
| Environmental condition | Humidity ≤ 98%, temperature 0-40 ℃ |
| Forming and bonding method | Adhesive tape, capable of meeting the support box requirements for laminated cardboard boxes and oil coated cardboard boxes |
| PLC | Siemens and touch screen from Germany |
